• Direct bolt-on replacement - no modifications required other than removal of the AGS (active grille shutters)


• +28HP and +45TQ gains on the dyno with no tune required (data in graph below)

• +31 degree reduction in Charge Air Temps. (IAT2) observed in real-world conditions (data in graph below)

• 58% greater internal core volume and 144% increase in external fin surface in comparison to the OEM intercooler


• High-flow cast end tanks (featuring the CVF logo) ensure considerably better airflow efficiency than welded aluminum


• TIG-welded bar-and-plate construction

• CVF Lifetime Warranty

LESS HEAT, MORE POWER

Improve the performance of your Bronco by replacing the small, inefficient stock intercooler to reduce heat and produce more top-end power. This intercooler is a direct fit replacement that features a core over 58% larger than the stock unit.

As the charts show in the images above, the CVF Performacne Intercooler saw Charge Air Temps. (IAT2) DECREASE -9 degrees compared to the OEM intercooler's +22 degree INCREASE during a 20 - 80 MPH run under similar conditions: the same stretch of road, the same vehicle, and in the same ambient temps. (the only change to the vehicle was the intercooler).

The CVF Performance Intercooler realized a whopping +31 degree improvement over the OEM intercooler in real-world street testing by an unbiased, third-party tester where it matters: on the street in day-to-day driving.

Taking it one step further, the above chart shows that on the dyno the CVF Performance Intercooler alone yielded a +28HP and +45TQ gain on a 2.7L model. Note that this is WITHOUT a tune, which would help enhance the gains even further.

EXCEPTIONAL CONSTRUCTION FOR MAXIMUM EFFICIENCY

Manufactured from top-grade aluminum, the CVF Performance Intercooler features a TIG-welded proprietary bar-and-plate design for maximum durability and fully cast end tanks (imprinted with the CVF logo) to ensure maximum flow of air into the unit and out to your turbo - equaling more HP.

APPLICATION AND INSTALLATION

This part installs on the following vehicles:

• 2021-2025 Ford Bronco 2.3L/2.7L engines

• 2024-2025 Ford Ranger 2.3L/2.7L engines

Fitments
